Q941F Electric Floating Ball Valve Overview

The Q941F Electric Floating Ball Valve is a floating ball valve driven by an electric actuator, designed with flange connections. The valve body is typically made of cast steel, stainless steel, or cast iron, and its internal ball can produce a slight floating displacement under medium pressure, tightly pressing against the outlet seat to form a seal. The valve operates via an electric actuator that drives the valve stem to rotate the ball by 90 degrees, enabling quick opening/closing or proportional regulation. The sealing pair often utilizes soft materials such as PTFE (polytetrafluoroethylene) to ensure reliable sealing. Powered by electricity, the valve operates automatically upon receiving control signals. It is widely used in fluid pipeline systems across industries such as petroleum, chemical, power, water treatment, and building automation, enabling remote or automatic control of media such as water, steam, oil, and gases.

Q941F Electric Floating Ball Valve Product Image

Q941F Electric Floating Ball Valve Features

1. Compact Floating Seal Structure: Utilizing a floating ball design, the ball moves towards the seat under medium pressure to achieve self-tightening sealing. This structure is simple, compact, and offers reliable sealing performance.

2. Intelligent Electric Control: Equipped with an integrated electric actuator, it enables precise on/off control and proportional regulation. It supports remote operation and integration with automation systems, significantly improving process control efficiency.

3. Excellent Sealing and Flow Performance: The soft-sealing valve seat ensures tight bidirectional sealing with a low leakage rate. The full-bore design minimizes flow resistance, making it particularly suitable for pipeline systems requiring high flow capacity.

4. Safe Operation and Easy Maintenance: The electric actuator features overload protection and manual/automatic switching functions. The valve’s simple structure reduces daily maintenance efforts, and the valve seat replacement is relatively straightforward.

5. Fire-Safe and Versatile Specifications: Typically designed with fire-safe and anti-static features, it can form a metal-to-metal secondary seal if the soft seal fails. Available in various materials, pressure ratings, and connection standards, it is widely applicable across different scenarios.
